Product Description
1. Optional chassis brand of portable water truck: Sinotruk.
2. Material of portable water truck :High Tension Steel Q235/Q345,stainless steel 304 for option.
3. Sprinking Width of portable water truck: ≥14M
4. Rear working platform with water cannon range of portable water truck: ≥28M
5. Reliable and high quality water pump
Applications:
1. water trucks are specialized vehicles equipped with large tanks in the rear for transporting water and controlled spray nozzles for distributing it – are a familiar sight in a variety of sectors such as civil construction, mining, farming and fire control.
2. The advantages they offer by transporting and disbursing both potable and recycled water can be put to a variety of uses too, and we will discuss them below so you can see how the addition of a water truck can actually improve operations in your own business.
3. Water trucks are especially useful in remote, rural areas where there are no fire hydrants to help put out fires. These trucks transport water needed by firefighters to not only control fires but dampening fire-prone areas that are likely to be consumed in the blaze.
| Chassis Specification | ||||
| Item No. | Parameters | |||
| Chassis Brand | SINOTRUK | Overall Dimension | 9800×2500×3250mm | |
| Gross Vehicle Weight | 28950 kg | Curb Weight | 8950 kg | |
| Loading Weight | 20000 Kg | Wheel Base | 3800 + 1400 mm | |
| Cabin | Row and half, Right Hand Driving | |||
| Engine | 371HP | |||
| Overhang( Front/Rear) | 1140/1810(mm) | |||
| Fuel type | Diesel | |||
| Axle load | 7000/13000/13000 (kg) | |||
| Angle(Approach/departure) | 16/22(°) | |||
| Transmission/Gearbox | 10 Forward & 2 Reverse Gear | |||
| Brake System | Pneumatic | |||
| Steering Gear | Power Assistant | |||
| Tire | 12.00R20, 10 Pieces with 1 spare tire | |||
| Maximum speed | 90(km/h) | |||
| Superstructure | ||||
| Water Tanker | Tank Volume | 18000 Liters / 18m3 | ||
| Tank Material | 5mm Q235B Carbon Steel | |||
| Sprinkling System: | Suction height of Truck Pump | >7m | ||
| Full Tank Suction Time | <15 minutes | |||
| Sprinkling width of front/rear/side Sprinkler | ≥14m | |||
| Range of Water Cannon | ≥28m | |||
| Remarks | Other Parts: Self-flow valve 1pc; Fire joint 1pc; Water pipe 2pcs | |||
