Description
1. Truck Chassis Main Specification:
(1) Sinotruk HW76 Flat Cabin, With one or Without Sleeper Bed. Air conditioner, Drive seat: Air Seat.
(2) WEICHAI Diesel Engine, WP10H400E62, 400HP, EURO-V, or Euro-VI.
(3) Steering Wheel: LHD, Left Hand Drive, Or Right Hand Drive is available.
(4) HW19710 Transmission/Gearbox, Manual control, 10 forward & 2 reverse
(5) Front Axle, Man 9.5Tons Capacity, 2 pieces; Rear Axle: MAN 16Tons, 2 pieces.
(6) Fuel Tanker: 400L, or 600L is available.
(7) Tire: 12.00R20, 12R22.5, 315/80R22.5 are for option.
2. Upper Equipment Specification:
(1) Hoisting/Underlift System: Max Under-Hoisting Capacity: 16000Kgs. Max Hoisting Weight under all extension: 7000kgs.
(2) Lifting Organ: Max lifting capacity:30000Kgs.
Basic Arm Length: 5200mm; Total Arm Length: 11200mm.
Max Lifting Height: 12000MM.
360 Degree Roatation.
(3) Winch: 2 pieces; Max Pulling Power: 15000Kgs*2, Total: 30000Kgs, 30Tons.
Steel Rope: 45 – 50 meters length, Diameters: 22mm.
(4) Landing Leg/ Outrigger: Front: 2 Pieces, Rear: 2 peices.
(5) Other accessories: Four sets of steel fork, a set of tow-fork sleeve, a set of steel plate hanging lug fork, a set of ABS device. A long warning light. Auxiliary light set, auxiliary pipe assembly
| Cabin | Driving type 8×4, Left hand drive | |||
| HOWO 76 cab, with air condition and one sleeper bed, 70°hydraulically tillable to the front as attached photo for ref. | ||||
| Vehicle Main Dimensions | Overall dimensions (L x W x H) mm | 11460×2500×3270 | ||
| Wheel base (mm) | 1800+4600+1350 | |||
| Wheel track (front/rear) (mm) | 2022/1830/1830 | |||
| Approach/Departure angle(°) | 16/18 | |||
| Weight in KGS | Tare Weight | 24870 | ||
| payload | 50000 | |||
| Front axles loading capacity | HF9 2×9000 | |||
| Rear axles loading capacity | HC16 2×16000 | |||
| Engine | Brand | Sinotruk | ||
| Model | WD615.47 | |||
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |||
| Horse Power(HP) | 371 | |||
| Emission standard | Euro-2 | |||
| HW19710, 10 Forwards gear & 2 reverse gear | ||||
| Tire | 12R22.5 tubeless tire with one spare | |||
| Clutch | Reinforced diaphragm clutch, diameter 430 mm | |||
| Steering | ZF8118 | |||
| Oil tank | 400L | |||
| Special Device For Wrecker System | ||||
| Towing | Max Towing weight(kg) | Above 50000 | ||
| Hoisting Organ | Max hoisting weight(kg) | 25000 | ||
| Max Under-hoisting Capacity (kg) | 12000 | |||
| Max Hoisting Weight under all extension(kg) | 12000 | |
| Max Under-hoist length (mm) | 2300 | |
| Extension Distance of oil Cylinder(mm) | 1850 | |
| Under hoisting work angle(°) | -10~85° | |
| Lifting Organ | Max lifting capacity(kg) | 50000 |
| Basic arm length(mm) | 5880 | |
| Total arm length(mm) | 11880 | |
| Telescope length(mm) | 6000 | |
| Max lifting high(mm) | 12000 | |
| Crane lifting angle | 3°~ 60° | |
| Crane rotation angle | 360°All Rotation | |
| Winch | Quantity | 2 |
| Max. Pulling power | 25000kgs*2 | |
| Winch rated hoisting force(KN) | 250×2 | |
| Steel rope | 50M length,Φ30 | |
| Landing Leg | Distance between front legs(mm) | 6600 |
| Distance between rear legs(mm) | 4080 | |
| Equipped | Four sets of steel fork, a set of tow-fork sleeve, a set of steel plate hanging lug fork, a set of ABS device. A long warning light. Auxiliary light set, auxiliary pipe assembly | |
