Philippines Design 20 Tons 22 m3 Roll on Roll off Garbage Truck for Waste Management Company
What is a Roll off Garbage Truck?
A hooklift truck is a heavy-duty truck chassis that’s been fitted with a hydraulic hooklift hoist. The hydraulic hoist system lets contractors, municipalities and other work vehicle users roll on and roll off different truck bodies or containers.Hook loader truck is also called roll off garbage truck,waste container vehicle,detachable compartment garbage truck, Hook lift garbage truck, Hydraulic hook lift truck, Hook lift rubbish truck with hydraulic system, Hooklift bin garbage truck,hook lift garbage truck,which is widely used for the transportation of garbage and coal ash in the garbage transfer station, garbage disposal plant, household domestic refuse collecting station, power plant and other places. The product uses the doemstic well-know second class chassis, and matches with various hydraulic lifting devices, providing you with the perfect and the ideal garbage transport tool.
Advantage of Roll off Garbage Truck
- A single hooklift truck can haul many types of truck bodies or containers. This can significantly cut costs for buyers, municipalities and others by reducing fleet sizes.
- one hooklift system-equipped truck with one driver, one license plate and one insurance policy can do the work of several; you just add truck bodies or containers as needed.
- Roll-on/off containers for hooklift trucks provide convenient, ground-level loading and unloading of materials.
- Hooklift trucks can easily position containers when you drop them off.
- with a hooklift-outfitted truck, roll-on/off bodies and containers can be switched out quickly. one container can be lifted or dropped in less than two minutes.
- Hooklift vehicle drivers can complete a pick-up or drop-off safely in the cab of their truck.
Main structures:
- The garbage compartment and the chassis can be completely separated,
- Reasonable structure,
- Simple and efficient operation,
- Good sealing performance,
- One car has multiple boxes, which greatly reduces the cost and space of spare parts.
| Truck Chassis | ||
| Item No. | Parameters | |
| Truck Chassis Model | QL1250UPCZY | |
| Overall Dimension | 9375 x 2500 x 3160 mm | |
| Gross Vehicle Weight | 24700 kg | |
| Curb Weight | 11500 kg | |
| Loading Weight | 12,000 ~18,000 kg | |
| Wheel Base | 4605+1350 mm | |
| Front /Rear Axle | 6700 kg / 18,000 kg x 2 | |
| Engine |
diesel engine
6UZ1-TCG40
Four Stroke,
6 Cylinder in line,
|
|
| Engine horsepower | 350HP/256KW | |
| Displacement | 9839 ml | |
| Rotating Speed | 2000 rpm | |
| Emission Standard | Euro IV | |
| Max Driving Speed | 90 km/h | |
| Gear Box |
|
|
| Cabin |
|
|
| Tire | 11.00R20, 10 Units with 1 Spare Tire | |
| Hook Lift System | ||
| Hook lift System | Lifting Capacity | 25Ton |
| Control | Hydraulic Control | |
| Control Handles | Mechanical Handle Control on side of truck | |
| Locking | 2 Side Locking System | |
| Garbage Box | Capacity | 22 CBM |
| Loading Weight | 15Ton ~ 20Ton | |
| Size | 5600 x 2300 x 1500 mm | |
| Material | Q235B Carbon Steel, 4mm Side, 5mm Bottom, | |
| Wheel | 2 Side Rear Steel Wheels | |
| Loading System | Hydraulic Hooking, Hydraulic Pulling & Tipping System | |
| Discharging System | Hydraulic Tipping for Discharging, Mechanical Opening Doors | |
