Description
| General Technical Parameters | |||
| Overall Dimension | 5990×2050×2500(mm) | ||
| Gross Vehicle Weight | 7360(Kg) | ||
| Curb Weight | 3760(Kg) | ||
| Chassis Specification | |||
| Chassis Brand | HOWO | ||
| Drive model | 4*2 | ||
| Cabin | Dongfeng, Single, LHD, with air conditioner | ||
| Number of Passengers | 2 | ||
| Engine | Model | 4-stroke direct injection , 4-cylinder in-line, intercooled supercharging, with ABS. | |
| Power | 81 KW/110 HP | ||
| Emission standard | EURO 2 | ||
| Fuel type | Diesel | ||
| Gearbox | 5 Forwards & 1 Reverse, manual operation. With power steering. | ||
| Brake System | Oil break | ||
| Wheel Base | 3300 mm | ||
| Front/Rear Axle Loading | 2000/5000(Kg) | ||
| Tire | 7.00-16, 6pcs with 1 spare tire | ||
| Max Driving Speed | 90(km/h) | ||
| Upperstructure Specification | ||
| Oil Tank | Effective Volume | 6CBM |
| Transport Oil Type | Diesel | |
| Tank dimension | 4000x1700x1100 | |
| Tank Thickness | 4mm | |
| Tank Material | Q235, carbon steel( also can choose stainless steel,aluminum ) | |
| Refueling System | 1. Oil pump;
2. Oil dispenser machine; 3. Hose reel with filling gun. |
|
| Equipment | 1. Manhole 1 Unit
2. Ladder handrail 3. Electrostatic Wire Reel 4. Loading, Discharge 5. Emergency cut-off valve 1 Unit |
|
| Options | Compartments, unloading valve, flow meter, API standard manhole, oil vapor recovery, anti-overflow probe. | |
Truck Diagram
