Description
1. Flatbed Size: 5600 x 2300mm inner size, Folded in the end
2. Flatbed Loading Weight: 5Ton
3. Under Lift Towing Weight: 4Ton
4. Major Equipment: Small Cart 2 Units, Towing Fixing Bracket, Bandles.
5. Towing Bar Lenght: 1640mm
Application:
Widely used in road, traffic, airports, docks, auto repair company,
industry and highway departments, timely, fast clean-up
accident, failure, illegal and other vehicles.
Optional Crane:
*SANY PALFINGER Crane
*XUGONG Crane,
1.Emergency Roadside Assistance:
– Accident clearance on highways (e.g., overturned trucks).
-Towing illegally parked vehicles in urban zones.
2.Disaster Response:
-Post-storm debris removal (fallen trees, flooded cars).
-Recovery of hazardous material spills.
3.Law Enforcement Support:
– Impounding vehicles in various operations.
– Counter-terrorism barrier removal.
Core Functions & Operational Capabilities:
Multi-Task Recovery Systems
- Hydraulic under lift over lift arms: Lift capacities from 2 to 80 metric tons (t).
- Rotary winches: 10-30-ton pulling force with steel cable or synthetic rope options.
- Stabilizing outriggers: Ensure operational safety during heavy-load recovery.
Modular Attachments
- Wheel-lift assemblies: For secure towing of passenger vehicles.
- Flatbed configurations: Hydraulic tilt beds (6-12m length) for damaged vehicle transport.
- Auto-clamping systems: Hydraulic jaws to immobilize wrecked vehicles.
| Chassis Technical Specification | ||||
| Chassis Parameters | Driving mode | 4X2 | ||
| Cabin |
–3 person, Left hand driving;
–2080 flat- topped, one row and a half cabin;
–Central controlled lock;
–Electrical door and window;
–With air conditioning, Remote key; –Power assisted steering.
|
|||
| Wheelbase | 4700mm | |||
| Engine | Engine brand | WEICHAI, WP4.1NQ200E62 | ||
| Horsepower | 200hp; 147kw | |||
| Displacement | 4.1L | |||
| Emission standard | Euro 6 | |||
| Transmission | Fast, Manual, 8 forward gears and 2 reverse gears | |||
| Font axle loading | 3,200kg | |||
| Rear axle loading | 8,500kg | |||
| Tyre | 8.25R20 16PR, 6 pieces + 1 spare tire | |||
| Suspension | 9/12+9B | |||
| Superstructure | ||||
| Flatbed | Length | 6,800mm | ||
| Width | 2,550mm | |||
| Max. Loading weight | 8,000kg | |||
| Min. Angle of slope | 15° | |||
| Platform height from the ground | 1,100mm | |||
| Checker plate thickness | 6mm (plate punching) | |||
| Winch | Quantity | 1 piece | ||
| Winch rating pulling capacity | 8,000kg | |||
| Length of steel cable | 25m | |||
| Rear -arm hoisting organ | Rating under-pulling capacity | 8,000kg | ||
| Fully extended max under-hoisting capacity | 2,500-4,800kg | |||
| Max under-hoist useful length | 1,340mm | |||
| Remarks |
|
|||
| Others |
–1.3m hydraulic flip plate at the tail;
–The frame of 16mm thick manganese plate
–A straight/folding crane can be installed as request
|
|||
