Description
Specification of dump truck:
| Engine | Diesel, 4 Sylinder in-line, turbo charged innter cooler | |
| Engine model: YC4D140-48 , Euro IV emission standard | ||
| 6-cylinder in-line with water cooling, turbo-charging and intercooling | ||
| Power: 140 hp | ||
| Displacement: 4.2L | ||
| Max torque | 450N·M | |
| Cluch model | ф325 | |
| Transmission | WLY 5T46, Manual, 5 forwards and 1 reverse | |
| Type of rear axle | QING TE 205 Hub reduction axle | |
| Speed ratio of rear axle | 6.578 | |
| Chassis | Frame: U-profile parallel ladder frame and reinforced subframe,all cold riveted cross members, Manganese steel | |
| Front suspension: leaf spring | ||
| Rear suspension:leaf spring | ||
| Aluminium fuel tank: 100 L capacity with locking fuel cap, fitted to the off side of the chassis | ||
| Wheels & Tyres | Tire: 9.00R20, 6pcs+1 spare tire | |
| Frame | 237×65×(7+4) | |
| Driver’s Cab | Single cab, with two seats, with a sleeper bed, with air conditioner | |
| Dimensions | Wheel base | 3300MM |
| Overall dimension | 5900*2300*2660mm | |
| Dump box | 3600*2100*650mm | |
| Weight kg | Loading Capacity | 6200KG |
| Curb weight | 5840KG | |
