Description
Product Specification
| CHASSIS | ||
| Brand and model | HOWO | |
| Drive type | 6X4 | |
| Wheel base(mm) | 3825+1350 | |
| Overall dimension(mm) | 7582*2495*3005 | |
| Curb weight(Kg) | 15600 | |
| Loading capacity(Kg) | 25000 | |
| Cabin | Flat roof, one and half rows, luxury configuration, 2 passengers allowable, with single bunker, with A/C | |
| Engine | Model | WP10.270E32 |
| Max.output (kw/HP) | 199/270 | |
| Max.torque (N•m) | 2200RPM | |
| Displacement (ml) | 9726 | |
| Emission standard | Euro3 | |
| Description | In-line, 6 cylinders,water cooled,4 strokes,turbo charged,inter-cooled,electric control,high pressure , common rail diesel engine |
|
| Gear box | Manual, 10 forward & 2 reverse gears | |
| Driving axle | Load capacity 15600Kg | |
| Front axle | Steering axle, loading capacity 7000Kg | |
| Quantity of leaf spring | 21/45 | |
| Inner trimming | ||
| Standard configuration | Air suspension seat | |
| Seat heater | ||
| Lumbar support to the driver | ||
| Adjustable steering wheel | ||
| Electrical system | ||
| Standard configuration | CAN bus intellectual electronic control system | |
| New battery box | ||
| Start/stop device under the vehicle | ||
| Safety | ||
| Standard configuration |
Three points safety belt | |
| Automatic clearance adjustment arm,tachometer | ||
| Service brake | Dual circuit compressed air brake | |
| Parking brake | Spring energy, compressed air operating on rear wheels | |
| ABS | Provided | |
| Comfortable accessories | ||
| Cab four points full floating suspension | Front and rear coil spring | |
| Standard configuration | Cab anti-rolling stabilizing device | |
| Hand accelerator | ||
| Electric window | Provided | |
| Tipper body | ||
| Standard configuration | Big tool box | |
| Reinforced rim (with HQ mark) | ||
| Three in one lock (Ignition switch, door and fuel tank) | ||
| Type specification | 12.00R20 | |
| Number of tyres | 10+1 spare tire | |
| Max.vehicle speed(km/h) | 77 | |
| Box dimension(mm) | 5600X2300X1400 | |
