Description
Product Description
Specification
|
Truck Model
|
CLW5042JGKJX
|
|
Dimensions & Weight
|
|
|
Overall Dimensions (L×W×H)
|
5995 × 2100 × 3200 mm
|
|
Gross Vehicle Weight (GVW)
|
4495 kg
|
|
Curb Weight
|
4300 kg
|
|
Wheelbase
|
3360 mm
|
|
Chassis & Powertrain
|
|
|
Chassis Brand
|
HOWO
|
|
Engine Power
|
115 hp
|
|
Displacement
|
2892 ml
|
|
Emission Standard
|
Euro 3
|
|
Transmission
|
5-speed manual + 1 reverse
|
|
Drive Wheel Configuration
|
4×2
|
|
Tire Specification & Quantity
|
7.00R16LT (6 tires + 1 spare)
|
|
Work Performance
|
|
|
Maximum Working Height
|
33 m
|
|
Maximum Working Radius
|
15 m
|
|
Platform Rated Load
|
200 kg
|
|
Maximum Personnel Capacity
|
2 persons
|
|
Platform Dimensions (L×W×H)
|
1600 × 700 × 1000 mm (High-strength stainless steel)
|
|
Key System Features
|
|
|
Boom Type
|
Seven-section octagonal arm, synchronous telescoping
|
|
Rotation
|
360-degree continuous
|
|
Outriggers
|
Front and rear V-type, individually adjustable (remote-controlled)
|
|
Control System
|
CAN bus system with wireless remote control, enabling stepless speed regulation
|
|
Leveling System
|
Static hydraulic automatic leveling
|
|
Emergency Operation
|
Manual emergency lowering device
|
|
Power Take-Off (PTO)
|
Mechanically operated
|
