Description
| Configurations | ||
| (1).Overall Parameters | ||
| Dimensions | Approx. Overall Dimensions | 8800*2450*3400 mm |
| Wheelbase | 4300 + 1350 mm | |
| Vacuum System | Tank Capacity | 16 CBM |
| Vacuum Pump | Jurop PN155, Italian Brand | |
| Powertrain Performance |
Max. Power | 280 kW/ 380 hp |
| Max. Torque | 1600 N·m | |
| Displacement | 9.726 L | |
| Emission Standard | Euro 3 | |
| (2).Chassis | ||
| Condition | Factory New | |
| Brand | Sinotruk HOWO | |
| Engine | Model | WP10.380E22 |
| Max. Power | 280 kW/ 380 hp | |
| Max. Torque | 1600 N·m | |
| Displacement | 9.726 L | |
| Emission Standard | Euro 3 | |
| Gearbox | Manual, HW19710, 10 forwards & 2 reverses | |
| Frame | (8+8/300) mm | |
| Suspension | Heavy duty leaf Spring, 10/12 | |
| Axles | Front | 7 tons |
| Rear | 16 tons*2, speed ratio 5.262 | |
| Tire | 12.00R20 18PR, 11 pcs including one spare | |
| Fuel Tank | 400 L | |
| (3).Superstructure & Equipment | ||
| Sewage Tank | Capacity | 16 CBM/ 16, 000 liters |
| Material | Carbon steel Q235 | |
| Thickness | 6mm shell, 8mm head | |
| Baffles | 2 nos. | |
| Vacuum Pump | Model | Jurop PN155, Italian Brand |
| Max. Speed | 1150 rpm | |
| Max. Air Flow | 910 L/min or 15200 m3/h | |
| Max. Vacuum Rate | 93 % | |
| Continuous Duty Vacuum | 60 % | |
| Oil Consumption | 240 g/h | |
| Suction Depth | 7 m | |
| Other Features | Water-gas separator | |
| Oil-gas separator | ||
| Four way valve | ||
| Safety valve | ||
| Anti overflow valve | ||
| Anti overflow warning device | ||
| Hydraulic control rear cover | ||
| Tipping sewage tank body | ||
| The color and LOGO are optional | ||
