Description
Sewage suction trucks, also known as Vacuum trucks, Sewer Jetting Truck,Sewer Cleaning Truck,Sludge Truck,Septic Tanker,Septic Truck,Suction Tanker,Waste Collection Truck. These trucks are used for a variety of purposes, including cleaning out septic tanks, sewage systems, and industrial waste. They are essential for maintaining sanitation and hygiene in urban and rural environments.
Truck advantages:
1. Chassis of vacuum sewage truck: Sinotruk Howo,
2. Vacuum sewage tank capacity could from 3cbm to 25cbm
3.Vacuum pump could be Chinese brand pump, or Italy brand such as Jurop, Moro, BP etc.
4.With high power vacuum sewage suction pump, high quality hydraulic system, and a double top self-unloading
mechanism, which enable the tank to directly discharge waste through the rear cover.
| Chassis Specification | ||||
| Chassis Parameters | Chassis Brand | Sinotruk Howo | ||
| Cabin | Right Hand Driving, Remote front door lock, with A/C | |||
| Engine | Model | WP12.400E201 | ||
| Power | 400HP | |||
| Emission standard | EURO 3 | |||
| Displacement | 1119L | |||
| Fuel type | Diesel | |||
| Gearbox | HW19710, manual type, 10 Forwards and 2 Reverses | |||
| Overall dimension | 9550*2500*3800mm | |||
| Front and Rear Axle load | 7.5T/16T+16T | |||
| Wheel base | 4350+1400mm | |||
| Brake System | Air Brake | |||
| Steering Gear | Power Assistant | |||
| Tire | 12.00R20, 10 Pieces with 1 Spare Tire | |||
| Maximum speed | 90(km/h) | |||
| Superstructure | ||||
| Tank body | Capacity | 11m3 sewage tank, 4m3 cleaning water tank, customizable | ||
| Tank material | Q235 carbon steel | |||
| Vacuum pump | Italy brand pump | Brand: Moro Kaiser | ||
| Model: PM110W | ||||
| CFM: 630 | ||||
| Rated suction speed: 1070m3/h | ||||
| Main parts | 1.Hydraulic cylinder 2.Pressure meter 3.Liquid level gauge 4.Anti overflow valve 5.Hydraulic control rear cover 6.Tipping sewage tank body 7.Anti-rust metallic paint, or as your requirement |
|||
